JC35N6

Load in push: 600N, 1200N

Load in pull: 600N, 1200N

Color: Black

IP grade: Max. IPX6

Stroke length:

600N：0-300mm

1200N：0-300mm

Installation dimensions:

L=S+155 (S≤300，Without Hall sensor)

L=S+170 (S≤300，With Hall sensor)

Noise level: ≤58dB, ( environmental noise≤40dB)

Hall sensor : optional

Mechanical end stop

Built-in electrical limit switch：None

Weight: About 0.7kg(different stroke length and installation dimensions with different weight )

Static bending moment: lateral load are not allowed.
