This product has been off the shelf!

loading

JCP35PA

Application field
Home Line,Medical Line

1. Low standby consumption with less than 0.5W

2. Ensures comfortable noise levels and constant speed levels to enhance the comfort of leisure bed users

3. Powers various home range systems and is often used for applications like recreational beds

4. As an external power supply, this application becomes a low voltage device



  JCP35PA-40 JCP35PA-50 JCP35PA-50B JCP35PA-100
Input Voltage 100~240VAC/50~60Hz
Output Voltage(VDC) 29
Output power(W) 40 50 50 (with 2*9V battery for emergency) 100
Power plug C TYPE Option Option Option
Color Black or Grey   Black
Connected control box JIECANG control boxes or relay free version
Output connector 01
Standby consumption Less than 0.5W
Duty cycle 10%, max,2min. continuous use
Overload Protection Buit-in
IP grade IP54
Ambient temperature +5°C ~ + 40°C
Certificate CE
