Motor	JC35LT2 400
Load	181kg (400lbs)
Weight	6.5kg①(without battery)
Size	212210127mm①
Fabric Belt Length	2200mm
Speed	25mm/s②
Battery Capacity	3.25Ah/6.5Ah 25.5V lithium ternary
Runs	78 times@3.25Ah③
Lifespan	22500 times
Safety features	Emergency stop, electronic emergency descent, mechanical emergency descent, free-fall braking, upper and lower limit detection, fabric tape slack detection, low battery alarm, overload protection

Rail Systems	JC35LT2
Dimension	515515108mm①
Weight	Rotating part diameter 235mm 12kg
Function	Electric rotary

Motor	JC35LT2 400
Load	181kg (400lbs)
Weight	6.5kg①(without battery)
Size	212210127mm①
Fabric Belt Length	2200mm
Speed	25mm/s②
Battery Capacity	3.25Ah/6.5Ah 25.5V lithium ternary
Runs	78 times@3.25Ah③
Lifespan	22500 times
Safety features	Emergency stop, electronic emergency descent, mechanical emergency descent, free-fall braking, upper and lower limit detection, fabric tape slack detection, low battery alarm, overload protection

Rail Systems	JC35LT2
Dimension	515515108mm①
Weight	Rotating part diameter 235mm 12kg
Function	Electric rotary
