Load in push:8000N,6000N
Color: Gray
IP grade: Max. IPX6W
Stroke length:
Standard:
8000N:50-500mm
6000N:50-500mm
Fast version:
6000N:50-300mm
5000N:50-300mm
4000N:50-300mm
3000N:50-300mm
Installation dimensions:
Standard:
L=225(S≤50)
L=S+175(50<S≤400)
L=S+195(400<S≤500)
Fast version:
L=225(S≤50)
L=S+175(50<S≤200)
L=S+185(200<S≤300)
Noise level: ≤50dB, ( environmental noise≤40dB)
Safety nut: optional
Hall sensor : optional
Only push no pull option : optional
Built-in electrical limit switch.
Weight: About 3kg (different stroke length and installation dimensions with different weight )
Static bending moment: lateral load are not allowed.
