Load in push：2500N,2000N,1500N,800N,500N
Load in pull：900N
Color: Gray
IP grade: Max. IPX6
Stroke length:
2500N：50-300mm (in steps of 4mm)
2000N：50-300mm (in steps of 4mm)
1500N：50-300mm (in steps of 4mm)
800N：50-300mm (in steps of 4mm)
500N：50-300mm (in steps of 4mm)
Installation dimensions:
L=S+170（50≤S≤200, standard）
L=S+190（200＜S≤300, standard; 50≤S≤200, only push）
L=S+210（200＜S≤300, only push）
Noise level: ≤58dB, ( environmental noise≤40dB)
Safety nut: optional
Hall sensor : optional
Only push : optional
Built-in electrical limit switch
Weight: About 0.8kg (different stroke length and installation dimensions with different weight )
Static bending moment: lateral load are not allowed
