Micro Linear Actuator
JIECANG
Product Parameters
JCLA00070081210/62D
JCLA01070081210/72D
Rated Voltage(VDC)
12
No-load Speed(mm/s)
18
Load Speed(mm/s)
8
No-load Current(A)
0.2
Max Push/Pull Force(N)
70
Max Static Holding Force(N)
100
Repeat Positioning Accuracy(mm)
±0.02mm
Stroke(mm)
10
Installation Distance
62
72
Force Control Included
No
Yes
Electric Actuator Size(mm)
13.2*11
Electrical Interface
LVTTL (I/O) Interface
Motor Type
Brushless
Note: Adjusting the lead screw pitch enables achievement of different speed and/or load capacities.
