Rated Thrust(N)
150
Fixed End Mounting Hole Diameter(mm)
φ4
Max Thrust(N)
500
Moving End Mounting Hole Diameter(mm)
Rated Linear Speed(mm/s)
50
Rated Voltage(VDC)
48
Max Linear Speed (mm/s)
100
Rated Output Power(W)
23.58
Stroke(mm)
45
Rated Torque(N.m)
0.075
Encoder Type
Multi-Turn Absolute Magnetic Encoder
Instantaneous Max
Torque(N.m)
0.23
Encoder Resolution
17-bit
Rated Current(A)
3
Weight(kg)
/
Instantaneous Max Current (A)
9
Screw Type
T-type Lead Screw
Rated Speed(rpm)
3000
Axial Play(mm)
Max Speed(rpm)
6000
Axial Mounting Distance(mm)
116
Rotor Pole Pairs
7
