Rated Voltage(VDC)
24 / 48
Brake
None / Friction Type
Peak Torque(Nm)
30
Reduction Ratio
80
Instantaneous
Max. Allowable
Torque(Nm)
40
Outer Diameter(mm)
50
Rated Torque(Nm)
10
Length(mm)
67 / 78.5
Rated Current(A)
4 / 2
Weight(kg)
0.41 / 0.5
Rated Speed(rpm)
37.5
Wiring Hole
Diameter(mm)
8
Module Power(W)
39
Positional Accuracy
(Output Side)
Repeatability: ±10 arc-sec
Absolute Accuracy: ±25 arc-sec
