Rated Voltage(V)
48
Temperature Rise @ Rated
80K@15min
Freeload Speed(rpm)
6000±10%
Total Loss(W)
26.32
Rated Power(W)
224.80
Torque Constant(N·m/A)
0.086
Rated efficiency η(%)
82
Pole Pairs
10
Rated Torque(N·m)
0.49
Rotor Moment of inertia J
(Kgcm2)
0.3
Rated Speed(rpm)
4381
Cogging Torque(mNm)
16
Peak Torque(N·m)
1.47
Torque Ripple Factor(%)
2
Line Resistance(Ω)
0.54±10%
Temperature Sensor
NTC(100k)
Line Inductance(mH)
0.35±20%
Total Weight(Kg)
0.14
Winding Connect Method
Y
Name
Magnet Wire Max.OD
Stator Outer DIM
Stator Lamination THK
Value
48Max
50
14
Potting Adhesive Height
Rotor Inner DIM
Rotor Height
23.5max
30
14.5
