Rated Voltage(V)
48
Temperature Rise @ Rated
80K@20 min
Freeload Speed(rpm)
3200±10%
Total Loss(W)
39
Rated Power(W)
322.01
Torque Constant(N·m/A)
0.164
Rated efficiency η(%)
83
Pole Pairs
14
Rated Torque(N·m)
1.23
Rotor Moment of inertia J
(Kgcm2)
0.6
Rated Speed(rpm)
2500
Cogging Torque(mNm)
24
Peak Torque(N·m)
3.63
Torque Ripple Factor(%)
2
Line Resistance(Ω)
0.465±10%
Temperature Sensor
NTC(100k)
Line Inductance(mH)
0.65±20%
Total Weight(Kg)
0.32
Winding Connect Method
Y
Name
Magnet Wire Max.OD
Stator Outer DIM
Stator Lamination THK
Value
75Max
76.2
15
Potting Adhesive Height
Rotor Inner DIM
Rotor Height
27Max
52
16
